BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current

Product Categories
Britec Electric Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current

Delivery time : 15days

Rated Voltage : 12V

Shipping term : TNT DHL FEDEX EMS UPS

Protection Class : IP 20

Customized : Yes

Model Number : BRBD-4L-12

Item Name : Signal system surge protector

Quality : 100%Brand

Place of Origin : China

Brand Name : BRITEC

Certification : CE

MOQ : 20 Piece/Pieces

Payment Terms : L/C,D/A,T/T,Western Union

Supply Ability : 50000 Piece/Pieces Month

Delivery Time : Shipped in 15 days after payment

Packaging Details : EXPORT PACKING

Package : Carton Package

Contact Now

12V Data Surge Protector Transmission Device SPD Network Surge Protective Device
Signal Surge Protective Devices Power Line SPDs for Data Transmission
Surge protection for use in measurement and control technology. Medium and fine protection.
  • Consists of a pluggable surge protection module and a base part for DIN rail mounting
  • Easy replacement of protection modules
  • All protection components integrated in the protection module
Product Details
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Model BRBD-4L-12
Test standards IEC 61643-21
SPD class TYPE2 P1
Nominal voltage Un 12V
Max. continuous operating d.c. voltage Uc 15V
Max. continuous operating a.c. voltage Uc 10.6V
Nominal current at 45℃ IL 1A
C2 Total nominal discharge current (8/20us) In 20kA
C2 Nominal discharge current (8/20us) per line In 10kA
Voltage protection level line-line for ln C2 Up ≤27V
Voltage protection level line-PG for ln C2 Up ≤600V
Voltage protection level line-line at 1 kV / us C3 Up ≤19V
Voltage protection level line-PG at 1 kV / us C3 Up ≤550V
Series impedance per line 1 Ohm
Cut-off frequency line-PG fG 2.8 MHz
Capacitance line-line C ≤1.0nF
Capacitance line-PG C ≤16pF
Operating temperature range Tu -40℃…+80℃
Enclosure material polyamide PA 6.6
Degree of protection (plugged-in) IP20
Dimensions
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Our Services
  • Sample service: sample offered
  • Fast & cost-effective shipping
  • Fast lead time
  • Best after-sale service
Applications
  • Protection against indirect lightning effects
  • Protect equipment with high-speed signal
  • For the protection of network equipment
  • Protect low frequency signalling application
  • It protects AC power supply of sensitive data equipment against lightning induced surges
Certification
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Shipping
By sea, By air, By express etc.
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Company Introduction
Britec Electric Wenzhou Co., Ltd. is specialized in the production of lightning protection. 17 years' experience, ISO, TUV & CE certificated, three-hours reach Ningbo port, this is how we keep superior quality and competitive offers for global valued customers. Our main products cover AC surge arrester, DC surge protection, data surge protector, lightning protective device, etc.
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Testing
BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current BRBD-4L-12 12V Rated Voltage Data Surge Protector with DIN Rail Mounting and 20kA Discharge Current
Frequently Asked Questions
Q1. English version is available?
A: Yes.
Q2. What is the lead time for delivery?
A: 15-30 workdays according to your quantity.
Q3. Do you have any MOQ limit?
A: 100pcs.
Q4. What express do you often use?
A: TNT, DHL, UPS, FedEx, etc. Any method you can choose!
Q5. What's your acceptable payment term?
A: Our usually payment term is T/T.
